Description
Disinfection Flow Rates
These flow rates are based on 95% UVT Water
– 16 mJ/cm2: 120 GPM (454 lpm)- 30 mJ/cm2: 80 GPM (303 lpm)– 40 mJ/cm2: 60 GPM (226 lpm)
– Adds state of the art UV technology to the K unit- Continuous feedback of UV performance for added peace of mind- Extends the range of the amalgam series with 2″ MNPT connections- Incorporates Cool-Touch fan technology- 230W power allow for recommended flow rates up to 80 GPM
Whether you are looking to fit a small school or a large hotel, Viqua has an UV disinfection solution to meet your needs. Viqua’s professional-grade equipment redefines reliability with rock solid performance under all environmental conditions.
Applications
– Schools, Daycares, eldercare, and healthcare facilities- Cottages and camps- Office and public buildings- Restaurants, hotels and resorts- Dairy and livestock
Replaces Obsolete UV Systems– Sterilight SM80Disinfection Flow Rate – 16 mJ/cm2: 120 GPM (454 lpm) – 30 mJ/cm2: 80 GPM (303 lpm) – 40 mJ/cm2: 60 GPM (226 lpm) Operating Parameters – Max. Operating Pressure: 100 psi – Ambient Air Temp: 32°F – 104° F – Influent Water Temp: 34°F – 113°F – Installation Orientation: Vertical
Electrical – Voltage: 120-240 VAC – Frequency: 50-60 Hz – Max Current: 3.0 A – Power Consumption: 230W
Dimensions – Chamber: 41″ x 4″ – Controller: 13″ x 6-1/2″ x 4-1/2″ – Inlet/Outlet: 2″ MNPT – Shipping Weight: 31 lbs
Options – Dynamic Flow Restrictor: No – Temperature Management Valve: CoolTouch Fan included – Solenoid Valve: Can be included – COMMcenter Control Package: Can be included
Features – Chamber Material: 316L SS – UV Sensor: Yes – Flow Meter: No – Cool Touch Fan: Yes – Visual “Power On”: Yes – Visual Lamp Life Remaining: Yes – Audible Lamp Failure: Yes – Audible Lamp Replacement Reminder: Yes – Sensor Reading Output (4-20 mA): No
Replacement Parts – Lamp/Quartz Sleeve Kit: 602850-103 – UV Lamp Only: 602856 – Quartz Sleeve Only: 602976 – UV Sensor: 650580 – Controller: 660018-R
