Description
Repeatable accuracy at any angle. 8 wide-contact ball bearings in rollerhead. Precision-machined track in heavy cast iron arm. Magnetic starter with no voltage/low voltage protection & thermal overload protection.
- Automatic electro-mechanical brake
- Auto-return device
- Low-voltage push-button controls
- Adjustable arm stop
208-230/460V, 5 HP, 3 phase, 3,425 RPM.
Blade dia. 14″, arbor 1″.
Cutting capacity: 4-1/8″, 1-3/4″ @ 45° bevel, 24″ crosscut.
Rip capacity: 37-7/8″.
Miter 15-1/2″ @ 45°.
Positive stop 45°.
Table 44″L x 33″W x 32″H.
Tool size 46″L x 47-1/2″W x 70″H.
Weight 500 lbs.
Includes TEFC w/automatic brake, upper & lower blade guard w/anti-kickback attachment, arbor nut, collars & wrenches, heavy steel base w/legs & Masonite® top, column lock & adjustable crosscut stop.
Blade not included, sold separately.
Please specify voltage.
