Description
Features:– Patented DryLoc connector with gold plated contacts
– Special design allows for installation at any angle, even inverted or horizontal
– Quick temperature response
– Easy sensor replacement using DryLoc electrode connector
– High temperature versions available
– Mounts into standard 3/4″ threads
– Compatible with all pH/ORP and other suppliers instruments
Applications:
– Water treatment and water quality monitoring
– Cooling tower and boiler protection
– Neutralization systems
– Sanitization Systems
– Pool and Spa Control
– Aquatic animal life support systems
Specifications
General
– Compatibility: Signet Models 2750 and 2760
– Tip Design: Bulb with protection
– Temperature Element: PT1000 RTD (PT1000 RTD for connection to the 8900 or 9900 when used with the 2750 sensor electronic)
– Operating Range: 2774/2776: 0 to 14 pH
2775/2777 +/-2,000 mV
– Process Connection: 3/4″, for use in reducing tees up to 4″
Wetted Materials
– Body: Ryton
– Reference Junctions: PTFE
– Sensing Surface: pH- Glass membrane
ORP- Platinum
– O-Rings: FPM
Max Temperature/Pressure Rating
– Operating Temperature: 32°F to 185°F
– Max Operating Pressure: 100 psi
