Description
Standard Model for liquid with 316 SS guide rods
F-400N Features
– Tough machined acrylic meter body, highly polished to a clear finish
– Direct reading permanent scale
– White back reflector makes for easy reading
– Sturdy adapters with high grade Viton o-ring seals
– Standard models have 316 stainless steel float guide rods
– Standard models have 316 stainless steel, PVDF or Teflon float (Optional Teflon)
– Acceptable in direct sunlight applications
– Available OEM options: Private labeling, custom calibrations, custom materials.
F-400N Specifications
| Adapter size | 1/4″ FNPT |
| Low Flow Reading | 0.025 GPM (0.1 LPM) |
| High Flow Reading |
0.250 GPM (1.0 LPM) |
| Adapter Material |
Polypropylene |
| Float Material |
PVDF |
| Max Working Pressure |
150 psi @ 70° F |
| Max Fluid Temperature |
Polypro Adapters: 150° F @ 0 psi |
| Full Scale Accuracy |
+/- 5% |
| O-Ring Seals |
Viton (optional EP) |
| Metered Body |
Machined acrylic |
| Approx. Ship Weight |
1/2 lb. |
* NIST certificates optional
