4" x 262" x 3" Double Acting Hydraulic Cylinder Simon Hydraulics 423547B T2145-33-LOD 04036700SH

4″ x 262″ x 3″ Double Acting Hydraulic Cylinder Simon Hydraulics 423547B T2145-33-LOD 04036700SH

Original price was: $1,399.95.Current price is: $279.99.

SKU: 902462 Category:

Description

4″ x 262″ x 3″ DA HYDRAULIC CYLINDER
Unused, old inventory. SIMON HYDRAULICS model 423547B welded cylinder with thread-in gland cap. Base end of cylinder has two 1/2″-13 x 1″ deep tapped holes.

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke4″ x 262″
  • Barrel Thickness1/4″
  • Pressure 3000 PSI max.
  • Rod Dia. 3″, Hollow
  • Rod Thickness 1/2″
  • Ports3/4″ I.D. Ports w/ 2″ Four-Bolt Flange, Code 61
  • Retracted Length 12-5/8″
  • Shpg. 780 lbs.
END MOUNTINGS
  • Rod End Tang
  • Max Thickness 4-15/16″
  • Pin Center to Tang End 1-3/8″
  • Pin Hole 1-1/2″
  • Trunnion Male
  • Pin Outside Width 9″
  • Pin Inside Width 6″
  • Pin Center to Rod Pin Center 12-5/8″
  • Pin Center to Base End 285″
  • Pin Diameter 2″
