Description
10″ x 72.5″ DOUBLE-ACTING TELESCOPING CYLINDER
Unused, old inventory. Three-stage telescoping cylinder. Superficial rust and interior rust, sold as-is. “P9077635 B389NE” stamped into cylinder barrel.
| SPECIFICATIONS |
- Double Acting, Telescoping
- Main Cyl Bore x Total Stroke 10″ x 72-1/2″
- Number of Stages 3
- Pressure 2000 PSI max.
- Rod Dia. 3-1/2″
|
- Extend Port 1″ Four-Bolt Flange, Code 62
- Retract Port 3/4″ Four-Bolt Flange, Code 62
- Retracted Length 40″
- Shpg. 650 lbs.
|
| END MOUNTINGS |
- Rod End Tang w/ Swivel Eye
- Max Thickness 1-15/16″
- Pin Center to Tang End 3-1/8″
- Pin Hole 2-1/4″
|
- Base End Tang
- Max Thickness 3″
- Pin Center to Tang End 3-3/16″
- Pin Hole 2-11/16″
|
