Description
Product details
| Gross weight |
1.96 kg |
| Net weight |
1.41 kg |
| Gross weight |
1.96 kg |
| Net weight |
1.41 kg |
| EAN |
5702423132584 |
| Ambient temperature max. [°C] |
70 °C |
| Ambient temperature max. [°F] |
158 °F |
| Connection material |
Brass |
| Electrical connection |
Box (metal/plastic) |
| Electrical connection size |
3 terminals |
| Enclosure rating IP |
IP65 |
| Insertion length [in] |
314.96 in |
| Insertion length [mm] |
8000 mm |
| Insertion type |
Variable |
| Output signal |
Ohm |
| Packing format |
Single pack |
| Process connection material |
Brass |
| Product group |
Sensors |
| Product name |
Temperature sensor |
| Protection tube diameter [in] |
0.18 in |
| Protection tube diameter [mm] |
4.5 mm |
| Protection tube material |
AISI 316 Ti |
| Quantity per packing format |
1 pc |
| Sensor elem. resistance [Ohm] |
100 Ohm |
| Sensor element [pc] |
1 pc |
| Sensor element standard |
EN 60751 |
| Sensor element tolerance |
Class B |
| Sensor element type |
Pt |
| Sensor Insert |
Fixed |
| Temperature range [°C] [Max] |
200 °C |
| Temperature range [°C] [Min] |
-50 °C |
| Temperature range [°F] [Max] |
392 °F |
| Temperature range [°F] [Min] |
-58 °F |
| Type |
MBT 5722 |
| Type designation |
MBT 5722-001-080-0102-000-0000 |
| Wires [pcs] |
3 pc |
| Ambient temperature max. [°C] |
70 °C |
| Ambient temperature max. [°F] |
158 °F |
| Connection material |
Brass |
| Electrical connection |
Box (metal/plastic) |
| Electrical connection size |
3 terminals |
| Enclosure rating IP |
IP65 |
| Insertion length [in] |
314.96 in |
| Insertion length [mm] |
8000 mm |
| Insertion type |
Variable |
| Output signal |
Ohm |
| Packing format |
Single pack |
| Process connection material |
Brass |
| Product group |
Sensors |
| Product name |
Temperature sensor |
| Protection tube diameter [in] |
0.18 in |
| Protection tube diameter [mm] |
4.5 mm |
| Protection tube material |
AISI 316 Ti |
| Quantity per packing format |
1 pc |
| Sensor elem. resistance [Ohm] |
100 Ohm |
| Sensor element [pc] |
1 pc |
| Sensor element standard |
EN 60751 |
| Sensor element tolerance |
Class B |
| Sensor element type |
Pt |
| Sensor Insert |
Fixed |
| Temperature range [°C] [Max] |
200 °C |
| Temperature range [°C] [Min] |
-50 °C |
| Temperature range [°F] [Max] |
392 °F |
| Temperature range [°F] [Min] |
-58 °F |
| Type |
MBT 5722 |
| Type designation |
MBT 5722-001-080-0102-000-0000 |
| Wires [pcs] |
3 pc |
Temperature range [°C] [Min]: -50, Temperature range [°C] [Max]: 200, Insertion length [mm]: 8000, Sensor element type: Pt, Sensor elem. resistance [Ohm]: 100, Protection tube material: AISI 316 Ti, Electrical connection: Box (metal/plastic), Electrical connection size: 3 terminals
