Description
Product details
| Gross weight | 0.16 kg |
| Net weight | 0.16 kg |
| EAN | 5702420013343 |
| Gross weight | 0.16 kg |
| Net weight | 0.16 kg |
| EAN | 5702420013343 |
| Connection size in | Rp 3/8 |
| Connection size out | R 3/8 |
| Differential pressure range [bar] [Max] | 0.6 bar |
| Dimension | 10 |
| Dimension standard | S |
| Flow temperature [°C] [Max] | 120 °C |
| Kv measuring range | 0.04 – 0.5 |
| Kv value at setting 1 [m³/h] | 0.04 m3/h |
| Kv value at setting 2 [m³/h] | 0.08 m3/h |
| Kv value at setting 3 [m³/h] | 0.12 m3/h |
| Kv value at setting 4 [m³/h] | 0.19 m3/h |
| Kv value at setting 5 [m³/h] | 0.25 m3/h |
| Kv value at setting 6 [m³/h] | 0.33 m3/h |
| Kv value at setting 7 [m³/h] | 0.38 m3/h |
| Kv value at setting N [m³/h] | 0.56 m3/h |
| Kvs values [m³/h] | 0.65 m3/h |
| Presetting | yes |
| Product group | Radiator Valves |
| Quantity per packing format | 90 pc |
| Test pressure [bar] | 16 bar |
| Type | RA-N (Normal flow valves) |
| Working pressure [bar] [Max] | 10 bar |
| Connection size in | Rp 3/8 |
| Connection size out | R 3/8 |
| Differential pressure range [bar] [Max] | 0.6 bar |
| Dimension | 10 |
| Dimension standard | S |
| Flow temperature [°C] [Max] | 120 °C |
| Kv measuring range | 0.04 – 0.5 |
| Kv value at setting 1 [m³/h] | 0.04 m3/h |
| Kv value at setting 2 [m³/h] | 0.08 m3/h |
| Kv value at setting 3 [m³/h] | 0.12 m3/h |
| Kv value at setting 4 [m³/h] | 0.19 m3/h |
| Kv value at setting 5 [m³/h] | 0.25 m3/h |
| Kv value at setting 6 [m³/h] | 0.33 m3/h |
| Kv value at setting 7 [m³/h] | 0.38 m3/h |
| Kv value at setting N [m³/h] | 0.56 m3/h |
| Kvs values [m³/h] | 0.65 m3/h |
| Presetting | yes |
| Product group | Radiator Valves |
| Quantity per packing format | 90 pc |
| Test pressure [bar] | 16 bar |
| Type | RA-N (Normal flow valves) |
| Working pressure [bar] [Max] | 10 bar |
